Carry 2
Carry 2 Dual-Bay Array System
Product Positioning:
Enterprise-grade external storage solution, designed as a stable and reliable data management platform for professional users. Combining clean design with stable performance, embodying the core values of simplicity, durability, and reliability while providing a cost-effective high-performance storage solution.
Hardware Design:
- Dual-bay array system design supporting 2.5"/3.5" HDD and 2.5" SSD
- Retains the classic handle and practical design of the Carry series
- Simple and robust structure, dimensions 24.5×15×12CM, weight 2.53kg (excluding drives)
- Front-mounted LED indicators for easy monitoring of drive activity and RAID status
Performance Specifications:
- Maximum capacity: Up to 48TB storage expansion capacity
- Transfer speed: Up to 500 MB/s
- Dual interface connectivity: Type-C USB 3.0 and SATA 3.0
- Theoretical transfer speed up to 5Gbps
- SATA III compatible with backward compatibility to SATA II
RAID Configuration Support:
Supports four RAID modes, providing diverse data protection and performance options:
-RAID 0 (Striping Mode)
Data is distributed across two drives, providing maximum storage capacity and fastest read/write speeds, suitable for applications requiring high performance.
-RAID 1 (Mirroring Mode)
Identical data is written simultaneously to two drives, providing complete data backup protection. Even if one drive fails, data remains secure.
-SPAN (Extended Mode)
Combines two drives into one large storage space, providing maximum storage flexibility.
-JBOD (Independent Mode)
Two drives operate independently, appearing as separate disk drives, providing maximum usage flexibility.
Core Technical Features:
-Stable Power Supply
Equipped with 12V 4A external power adapter (48W), ensuring stable long-term operation and reliable, consistent data transmission.
-Intelligent Cooling System
Equipped with 50x50mm intelligent temperature-controlled silent fan, ensuring stable long-term operation. AI intelligent sleep mode automatically enters energy-saving state after 10 minutes of idle time.
-Hardware RAID Support
Built-in hardware RAID support provides low latency, stable data transmission, and efficient heat dissipation.
Compatibility and Connectivity:
Plug-and-Play Design
Fully compatible with mainstream operating systems, including Mac OS X 10.X, Windows 8/10, Linux, with no driver installation required.
-Extensive Device Testing
Tested and verified with mainstream devices including MacBook Pro, Surface Pro, Asus ZenBook.
Target Application Areas:
- Professional media production
- Security surveillance system data access
- Office environment storage expansion
- Cloud data storage and server applications
Technical Advantages:
